Description
-
Trouble-free continuous operation :Closes bags at ease on the bagging line or in the field.
-
Quiet operation :High-grade, wear-resistant nylon cam ensures minimum noise level in comparison to loud noise experienced in machines with steel cams during operation.
-
Safety handle :Strong plastic handle for insulation.
-
Non-corrosive finish :Essential as it helps resist corrosion in damp and humid conditions.
-
Superior powerful lubricator : Lubrication system consists of an oil pump and a reservoir. Oil lines from the pump direct the lubricant to the main moving parts.
-
Sealed Motor : Ideal as it provides the motor with a total dust-proof enclosure.
-
Automatic thread cutter :Protected cutting blades sever the thread after the bag is closed.
-
Timing Belt :15mm toothed belt helps the machine operate without much effort under tense workload.
-
Adaptable :Stationary or suspended use can be attained from this machine without loss of useful portable features.
-
Presser foot lifter and thread cone cover : Standard in all bag closing models.
-
Optional accessories : Conveyor stands, shoulder belts, spring balancers with hangers are available at extra cos
SPECIFICATIONS
SEWING SPEED : Efficient production: Maximum sewing speed 1600-1800 stitches per minute
DIMENSIONS : 12in. H x 12in. W x 13in. D (30 cm x 30 cm x 33 cm)
STITCH LENGTH : 3.5 stitches/inch (25.4mm) Fixed
MAXIMUM MATERIAL THICKNESS : 10mm
CUTTER TYPE : Mechanical
THREAD : 8oz. Cotton or Synthetic thread cones.
NEEDLE SIZE : DB X 1 200/25 Groz-Beckert
POWER REQUIREMENTS : 220V
WEIGHT : 6 kg.
TYPE OF STITCH : Single thread/chain stitch
CLOSING-SPEED : 5 - 8 sec/bag, 39 fpm at 3.5 stitches/inch (25.4mm)
TYPES OF BAGS : All kinds of multi-wall paper, kraft-paper, burlap, cotton, PP/PE, Hessian, woven polyester, jute bags etc
LUBRICANT : For extended lubrication and wear, use SAE 30 Oil
